This tutorial was originally published on the 1st November 2014. It has been updated to show the use of the new Insert Shapes tool and the Align tool. If you don't have a Cricut cartridge that has a swing card on it, it's easy to create your own using the slice feature.
In this tutorial I'll be showing you how to make a swing card that when folded measures 4.25" x 5.5".
Let's get started...
Select
Insert Image and select a decorative shape to add to your canvas. I'm using the
Note Card with the image number #M3F06D from the Cricut Craft Room Basics image set. This image is free to all Design Space users.
Click the
Insert Shapes tool, then click on the score line and the square shape to add them to the canvas. Click anywhere on the canvas to close the Insert Shapes box.
Click on the Note card shape and from the bottom of the Layers panel, click
Duplicate.
Move the duplicate off to the side as you'll need it later.
Select the square, then from the
Edit box click the K
eep Proportions (the lock) button to unlock it.
Resize the square to
6.75" width and
5.5" height.
(Tip: Use the Tab button to move between the width and height boxes. The same applies to the X & Y boxes.)Move the rectangle to the top left of the canvas (X 0.00" and Y 0.00")
(Why do I do this? It makes it easier to work out where the score marks need to go.)
To make the score lines more visible you can change the colour of the rectangle if necessary. Click on the square in the Layers box then select a colour.
Please note: As this tutorial has been updated since first posting, some of the shapes in the new screen shots will be a different colour. Click on the score line and move it to
X 2.75" and
Y 0.00"
With the score line still selected click
Duplicate. Your score lines will go missing at this point. They are just hidden behind the rectangle.
Click on the rectangle then from the top toolbar click
Arrange. Click
Move to Back to move the rectangle behind the score lines.
Move the second score line to
X 4.00" and
Y 0.00"
Use
Ctrl + click to select both score lines from the Layers box then click Duplicate.
Position them at the bottom of the rectangle and at X
2.75 and
X 4.00. (Don't worry about the length of the score lines at this point as we'll change them after we have added our decorative shape.)
Select your decorative shape then click the
Show button in the
Layers box. The shadow will appear.
Select the shape and its shadow and resize the
width to 4.2". Leave the Lock Proportions button locked unless you want to manually resize the height.
Note: The size of this shape cannot exceed the width of the finished card. In this case the finished width of the card is 4.25" which is why I'm making my shape 4:20" wide.
Click
Ungroup from the bottom of the
Layers box.
Click on the
top layer and change the
width to
4.15".
Select both layers of this shape and click
Align, Center.
With both layers of the decorative shape still selected click the
Slice button at the top of the
Layers panel.
Your image will change colour.
Move the top (black) layer of the image off to the side and delete it. You'll be left with just the frame of your image.
Next we need to centre this image on the rectangle.
From the
Layers box use
Ctrl + click to select the
rectangle and the
four score lines.
Click
Group from the bottom of the
Layers panel.
Move the rectangle away from the top left corner of the canvas then click
Ungroup.
Select the sliced shape and move it over the rectangle. (Click
Arrange, Move to Front if you can't see the shape.)
Select both the shape and rectangle. (
Not the score lines.)
Click
Align, Center.
Next we need to remove the centre section of the shape.Add a square to your canvas using the Insert Shapes tool and move it over the rectangle.
Position the square so that it is vertically higher than the note card shape.
Drag your mouse around one of the left most score lines and take note of its X position from the Edit panel.
Click on the square and change its X position to the same as the score line.
Drag the bottom right handle and stretch the square so it's taller than the sliced out decorative shape.
From the
Edit panel click on the
Unlock button on the square and change the
width to 1.25"
The new rectangle should now fit inside the two vertical score lines and extend above and below the decorative shape.
Select just the
small rectangle and the
decorative shape. (Select them using Ctrl+click in the Layers menu if you have trouble.)
Click
Slice. The shape will change colour.
Drag the two pieces from the middle of the large rectangle over to the side. You can delete them as you won't be needing them again.
If you accidentally move the decorative shape click Undo and try again. (Click towards the top of the small rectangle.)
Select what's left of the
decorative shape and the
large rectangle and again click
Slice. (Check your layers box to make sure just those two images are selected.)
Click inside the decorative shape and move it to the side and you're left with....
You can delete the sliced piece (the piece on the right in the image above) as you won't be needing it again.
Your score lines will probably have gone missing again. Just send the rectangle to the back again using the
Arrange button.
Adjust the height and position of your score lines so the top ones touch the top of the decorative shape and the bottom ones touch the bottom of the shape.
Drag your mouse around the rectangle to select both it and the score lines and click
Attach. (Or you can select them from the Layers panel.)
That's the base layer done... now we'll create the panels for the sides and centre of the card.Click the
Insert Shapes button and add a square to your canvas.
Turn off the lock in the Edit box and change the dimensions to
width 2.63" and
length 5.38"Duplicate that rectangle
twice.
Change the width of
one of the rectangles to
1.13". (Unlock the proportions first by clicking on the lock.)
Place the two wider rectangles on the left and right sides of the card and the other rectangle in the middle section of the card. (I've change the colour of the large rectangle at this point to make it easier to align the other rectangles.)
Select the three new rectangles then click
Align,
Align Top.
Move the rectangles left and right so they have equal space between them. Use the X position in the Edit box if necessary to move them .01" to the left or right.
(Make sure your DS screen isn't zoomed at this point. It's a known bug that if your screen is zoomed and you change the number in the X or Y box it won't move the object to the correct position. You must have your zoom at 100%.)Select all
four rectangles then
Align, Center VerticallySelect the remaining decorative shape from the Layers panel and click on the eye next to the shadow layer to show it.
Resize it to a
width of 4.37". (Don't unlock the proportions.)
Select
Ungroup from the
Layers menu.
Move the top layer off to the side then move the shadow layer over the rectangles of your card base.
From the
Layers box select the decorative shape and the large rectangle. (
Not the three smaller rectangles. You may have to click on a blank section of the canvas first to get this to work.)
Select
Align, Center. The decorative shape will now be perfectly centered over the rectangles.
Click anywhere on the canvas then click on the
decorative shape and the
left rectangle then click
Slice from the Layers menu.
Click the
decorative shape and the
middle rectangle and click
Slice.
Click the
decorative shape and the
right rectangle and click
Slice.
Drag your mouse around the sliced shapes (start to the left of the large rectangle) to select them, move them to the side then delete them.
Select your remaining shape and resize it to a
width of 4".
Click
Duplicate from the Layers panel.
Use these two shapes on the front and back of the swing section of the card.
If you want panels for the back of the card select the three existing panels and duplicate them from the Layers panel.
And call it done!
Happy crafting! �
